drone and propell aircraft model 6.5KG Torque DC motor manufactur-myfrd-myhobby

drone and propell aircraft model 6.5KG Torque - 6500 DC motor manufacturer supply

Tech Parameter :

Battery :Li-Po 4S-8S

KV:270/320/380

Max.RPM:12000

THRUST: 6500G

TORQUE: 1.4N.m

NET WEIGHT: 370G

MAX VOLTAGE: 30V

MAX CURRENT: 80A

MAX POWER: 2160W

Item Size :50mm*65mm

Propeller Size mm :1718/1920/2022

Where to use ?

 6500 DC brushless motor ,

 provide a strong driving force and high power output for the drone, giving enough thrust to allow the drone to take off, fly and perform various actions. For example, each rotor of a multi-rotor UAV is driven by a DC brushless motor.

 By controlling the speed of different motors, the UAV can rise, fall, advance, retreat, move left and right, and hover. At the same time, it supports joint of the complete high speed and frequent positive and negative rotation to achieve high degree of freedom of action, so there are higher requirements for the performance of the motor and driver chip in order to complete the torque control more quickly and accurately
